Welcome to Brakeza3D!
Brakeza3D is a simple and powerful cross-platform 2D/3D game engine designed for indie developers and small teams.
It features a clean, component-based architecture, a built-in scene editor, and full Lua scripting support and GLSL shaders, allowing developers to prototype and build games quickly and efficiently.
Purpose of this document
This document is designed for programmers who wish to use Brakeza3D in their own projects. Throughout this documentation, you will find detailed information about how the application works and the features it offers, enabling you to develop amazing things on your own!
This document is currently in BETA. We are continuously working on it.
Technologies used
Brakeza3D is designed entirely from scratch and integrates third-party libraries to provide a complete and self-contained solution.
| Technology | Description | Official Link |
|---|---|---|
| C++ | Main programming language | https://isocpp.org |
| SDL2 | Window management and input handling | https://www.libsdl.org |
| SDL2_image | Image loading library for SDL | https://github.com/libsdl-org/SDL_image |
| SDL2_ttf | Font rendering library for SDL | https://github.com/libsdl-org/SDL_ttf |
| SDL2_mixer | Audio playback library for SDL | https://github.com/libsdl-org/SDL_mixer |
| Bullet Physics | Physics engine | https://pybullet.org |
| Assimp | 3D model importer | https://www.assimp.org |
| OpenGL | Graphics API | https://www.opengl.org |
| GLM | OpenGL Mathematics library | https://github.com/g-truc/glm |
| Lua 5.2 | Scripting language | https://www.lua.org |
| ImGui | Immediate mode graphical user interface | https://github.com/ocornut/imgui |
Features
- Cross Platform (Windows/Linux/OSX checked)
- Easy and simple architecture
- Render Forward/Deferred
- ADS light system
- Physics World Integration
- GUI with docking integration
- Assimp library for loading models
- Scene management
- 2D / 3D features
- Profiler
- Shadow mapping
- LUA Scripting
- Extensible GLSL Shaders / Nodes editor
- Code editor with LUA/GLSL syntaxis integration
- Sound system integration
- Interface for XBOX/Playstation controller
- Multi-Thread (Thread pool based)
License and usage terms
Brakeza3D is released under the GNU General Public License v3.0 (GPL-3.0).
You are free to use, modify and distribute this software, provided that:
- Any derivative work is also licensed under GPL-3.0
- Source code is made available
- Copyright and license notices are preserved
- This software is provided without any warranty.
For full license details, see the LICENSE file or visit: https://www.gnu.org/licenses/gpl-3.0.html
